CATALYST REGENRATION VOLVO V70 2.4 2000 year

1257 Views 0 Liked
1 Comment
(5)
Posted on: 2023-07-11


Another cool classic with a faulty catalytic converter has come to us. Five-cylinder inline with 170 km of power. Originally installed was a metal cartridge which rarely happens. Despite the fact that metal inserts are more resistant than ceramic ones, they withstand gas and any mechanical damage better, with time the metal insert needs to be replaced due to natural wear of elements responsible for catalyzing exhaust gases.

Standard is to cut the housing with a band saw, bite into the ceramic catalytic converter insert with an eccentric cutter and that's it, but in this case removing the original insert was a real challenge. A hammer drill, hammer, chisel, cutter and countless k-words were in motion ;-) But we managed to pull it out and clean it in preparation for the installation of a new cartridge. After measuring the inner diameter of the catalytic converter housing, we selected a 125 mm diameter cartridge that fit perfectly into the housing. Of course, it is necessary to weld carefully from the inside anyway, so that the exhaust gases do not bypass the catalyst core through leaks, and so that the cartridge is firmly attached to the housing and does not make any disturbing sounds.  The cartridge, as the factory predicts, is of the same capacity as the original, which is 400 cpsi, and meets the emission standards in accordance with the Euro 4 standard. The exact data of the cartridge used for this regeneration can be found at the link - link.

After welding the cartridge from the inside, we also weld the catalyst housing on the outside. All welded using TIG method to maintain the original and aesthetic appearance of the catalytic converter.

Catalyst cartridge used for this regeneration: Universal catalytic converter insert EURO 4 AWG

1. Catalytic converter before regeneration

2. Original metal catalytic converter insert

3. Original catalytic converter insert (close-up)

4. Damaged original catalytic converter insert from housing

5. Inserted new cartridge into original casing

6. Removal of old cartridge

7. New cartridge before welding


8. Welded Euro 4 cartridge with 125 mm diameter

9. Catalytic converter after regeneration

10. Welded after regeneration


Czy ten wpis na blogu był dla Ciebie pomocny?
Posted in: News, Cars,

Leave a comment

Security code

Comments

  • Citroen C 5 2.0 benzyna 140km 2005r
    By: Maciek Żurowski On 2023-07-14
    Rating:
    5.0

    Dzień dobry ,jaki jest koszt regeneracji katalizatora w C 5 .
    VIN VF7RCRFJF76727068

    Replied by: Rafał Białousz On 2023-07-14 Dzień dobry. Koszt regeneracji uzależniony jest od średnicy wkładu katalizatora. Trzeba zmierzyć średnicę obudowy odejmując wszelkie osłony termiczne oraz grubość ścianki udowy. Myślę, że będzie tam wkład o średnicy 11 cm z normą emisji spalin Euro 4 bo taka wychodzi z nr vin. Koszt wkładu 1135 pln - https://kat-eko.com/pl/uniwersalne/278-1408-wklad-katalizatora-uniwersalny-euro-4-awg.html#/37-dlugosc_wkladu-100_mm/47-srednica_wkladu-110_mm/57-norma_euro-euro_4. Koszt regeneracji, czyli przespawanie wkładu to 250 pln. Robimy to w jeden dzień.
