Gasoline catalytic converter core AWG

Gasoline catalytic converter core AWG

1,095.93 zł
Shipping in 24h
STANDARD-E4/125/100
Catalyst application
Gasoline
Cartridge type
Standard
Cartridge material
Metal
Producer
AWG Polonez
euro standard : Euro 4
Inlet diameter : 125 mm
Insert length : 100 mm
Capacity (cpsi) : 500
Quantity
Add to wishlist
Last items in stock

help_outlineAsk about product
Gasoline catalytic converter core AWG

Gasoline catalytic converter core AWG



Place an order within 04h 33m 12s And we will send your order today



Download PDF

Universal metal catalytic converter insert for welding into the housing (manifold). Compatible with gasoline engines and LPG systems.

Catalytic converter, depending on the selected configuration, meets the requirements of the European Directive:

  • Euro 2 Directive 94/12/EC, 96/69/EC for passenger cars, effective from 1996.
  • Euro 3 Directive 98/69/EC [12] for all vehicles, effective since 2000.
  • Euro 4 Directive 98/69/EC, 2002/80/EC for all vehicles, effective from 2005
  • Euro 5 Directive 2007/715/EC[13] for light passenger and company cars. Effective from 2009.
  • EURO 6 Commission Regulation (EU) No. 459/2012. Effective from 2014.

Manufacturer's warranty: 12 months or 50,000 km.

The catalytic converter cartridge is selected based on the emission standard it is supposed to meet and its dimensions. Unfortunately, no catalog gives the dimensions of the cartridge, because theoretically it is a non-interchangeable part, so in order to properly select the cartridge you need to measure the diameter and length of the catalytic converter housing. Then subtract the thickness of the wall of the catalytic converter housing, since the cartridge is located inside the housing. For example, when the catalytic converter housing has a diameter of 120 mm, a cartridge with a diameter of 115 mm would be suitable.

STANDARD-E4/125/100
2 Items
  • Catalyst application Gasoline
  • Cartridge type Standard
  • Cartridge material Metal
  • Producer AWG Polonez

Specific References

ean13
5905601231776
